Command line 26
Item
Description
Values include "Enabled" and "Disabled".
IpAddress (Required
if DomainIP is
enabled)
A valid IP address to use for the domain IP address configuration. The IP address
must be in the format xxx.xxx.xxx.xxx, where x is a number between 0 and 9, for
example, 192.168.0.10.
SubnetMask (Required
if IP address
specified)
A valid subnet mask for the domain IP address configuration. The subnet mask must
be in the format xxx.xxx.xxx.xxx, where x is a number between 0 and 9, for
example, 255.255.255.0.
Gateway (Required if
IP address
specified)
A valid gateway address for the domain IP address configuration. The gateway
address must be in the format xxx.xxx.xxx.xxx, where x is a number between 0 and
9, for example, 192.168.0.1.
DomainIpv6
(optional)
Enables or disables the VC domain IPv6 address. If enabled, you must configure a
valid IPv6 address.
Enabling a domain IPv6 address configuration or changing the domain IPv6
address can cause a temporary loss of connectivity to the VCM. Use caution when
changing these settings.
Values include "Enabled" and "Disabled."
Ipv6 Address
(optional)
A valid IPv6 address to use for the domain IPv6 address configuration. The IPv6
address must be specified with a prefix, for example, 2001::3/64.
Ipv6Gateway
(Required if an IPv6
address is
specified)
A valid IPv6 gateway for the domain IPv6 address configuration, for example,
2001::10.
MacType (optional) The type of MAC address source to use for assignment. Values include
"VC-Defined", "Factory-Default", and "User-Defined".
MacPool (optional) The pre-defined MAC pool to use for address assignment. Values include integers
from 1 to 64. This property is valid only if the MacType is set to "VC-Defined". If not
specified, the default pool ID is 1.
Carefully choose the pool so there are no conflicts with other addresses in the
environment.
MacStart (Required
if MacType is
User-Defined)
The starting MAC address in a custom user-defined range. This property is valid
only if the MacType is set to "User-Defined".
MacEnd (Required if
MacType is
User-Defined)
The ending MAC address in a custom user-defined range. This property is valid
only if the MacType is set to "User-Defined".
WwnType(optional)
The type of WWN address source to use for assignment. Values include
"VC-Defined", "User-Defined", and "Factory-Default".
WwnPool(optional)
The pre-defined WWN pool to use for address assignment. Values include integers
from 1 to 64. This property is valid only if the WwnType is set to "VC-Defined". If
not specified, the default pool ID is 1.
Carefully choose the pool so there are no conflicts with other addresses in the
environment.
WwnStart (Required
if WwnType is
User-Defined)
The starting WWN address in a custom user-defined range. This property is valid
only if the WwnType is set to "User-Defined".
WwnEnd (Required if
WwnType is
User-Defined)
The ending WWN address in a custom user-defined range. This property is valid
only if the WwnType is set to "User-Defined".
SingleDense
(optional)
If the imported domain supports double-dense server blades, this property enables
the device bay display format to support the display for single-dense servers along
with the double-dense servers. In a double-dense supported configuration, the
default for this property is false, which disables the display of single-dense servers.
