Command line 38
Item
Description
Name (optional)
The new name of the fabric
Speed (optional) The port speed for the uplink ports in the fabric. Values include "Auto", "2Gb", "4Gb",
and "8Gb". The default port speed is "Auto".
Speed restrictions:
•
For the HP VC 4Gb FC Module, if the value 8Gb is chosen, VCM translates the
value to "Auto", which allows the module to connect to the SAN switch at optimal
speed.
•
For the HP VC 8Gb 24-Port FC Module, HP VC 8Gb 20-Port FC Module, and HP
VC FlexFabric 10Gb/24-port Module, valid speed values include
"Auto","2Gb","4Gb", and "8Gb".
LinkDist
(optional)
Specifies the login re-distribution scheme for load balancing. Values include "Auto"
and "Manual". The default login re-distribution is "Manual" for a "FabricAttach"
fabric. Login re-distribution is not supported for "DirectAttach" fabrics.
The HP VC 4Gb FC Module, HP VC 8Gb 20-Port FC Module, and HP VC 8Gb 24-Port
FC Module support only manual login re-distribution. The HP VC FlexFabric
10Gb/24-port Module supports both auto and manual login re-distribution.
Ports (optional) A list of one or more logical FC ports to be added to the fabric. Specify each port in the
format "
modified in the fabric (affects all modules within a bay group).
For HP VC FlexFabric 10Gb/24-port Modules, port numbers 1, 2, 3, and 4
correspond to ports X1, X2, X3, and X4, respectively.
PrefSpeedType
(optional)
Preferred connection speed for any FCoE connection attached to this fabric. Values are
"Auto" and "Custom". "Custom" allows the user to configure the speed. The default
value is "Auto". This property is configured only if the fabric has uplink ports from the
FlexFabric interconnect module.
PrefSpeed
(required if
PrefSpeedType is
"Custom")
The preferred connection speed for any FCoE connection attached to this fabric. Values
range from: 100Mb-8Gb in 100Mb increments. This property is configured only if the
fabric has uplink ports from the FlexFabric interconnect module.
MaxSpeedType
(optional)
The maximum connection speed for any FCoE connection attached to this fabric.
Values are 'Unrestricted' and 'Custom'. 'Custom' allows the user to configure the
desired speed. The default value is 'Unrestricted'. This property is configured only if the
fabric has uplink ports from the FlexFabric interconnect module.
MaxSpeed
(required if
MaxSpeedType is
"Custom")
The maximum connection speed for any FCoE connection attached to this fabric.
Values range from: 100Mb-8Gb in 100Mb increments. This property can be
configured only if the fabric has uplink ports from FlexFabric interconnect module.
Examples
->set fabric MyFabric1 Name=MyNewName1
Changes the name of an existing fabric
->set fabric MyFabric2 Speed=2Gb LinkDist=Auto
Modifies the port speed and login re-distribution
->set fabric MyFabric3 Ports=1,2,3,4
Modifies the fabric ports contained in the fabric
->set fabric MyFabric5 -loadBalance
Performs load balancing on a fabric with manual login re-distribution
->set fabric MyFabric4 PrefSpeedType=Custom PrefSpeed=4000
MaxSpeedType=Custom MaxSpeed=8000
Modifies the fabric to preferred connection speed of 4Gb and maximum connection
speed of 8Gb
Item
Description
show fabric
Display all fabric information.
