Command line 116
Item
Description
->show statistics -summary LAGID=enc0:1:lag25
Displays aggregated statistics with selected counters for a given LAG ID on
interconnect module 1 of the primary enclosure
->show statistics LAGID=enc0:1:lag25
Displays aggregated statistics for a given LAG ID on interconnect module 1 of the
primary enclosure
In addition to the standard statistics, Virtual Connect also provides additional information on DCBX and QoS.
The QoS statistics are displayed for the specified physical port. The types of QoS statistics are in the format
of cosq
the egress dot1p priority of the corresponding QoS traffic class. When QoS is not enabled, cosq3 is for FCoE
traffic and cosq0 is for regular Ethernet traffic.
The following table lists the types of QoS statistics displayed.
Item
Description
cosq
The accumulated transmitted byte count of unicast packets of the queue for
the specified port. For VC FlexFabric 10Gb/24-port module and VC
Flex-10 Enet module, the counter is not supported and the value is 0.
cosq
The accumulated transmitted packet count of unicast packets of the queue
for the specified port. For VC FlexFabric 10Gb/24-port module and VC
Flex-10 Enet module, the counter includes both unicast and multicast data.
cosq
The accumulated dropped packet count of unicast packet of the queue for
the specified port. For VC FlexFabric 10Gb/24-port module and VC
Flex-10 Enet module, the counter includes unicast and multicast data.
DCBX is the data center discovery and capability exchange protocol used by DCB devices to exchange
configuration information with directly-connected peers. The protocol can also be used for misconfiguration
detection and for configuration of the peer. In this release, the VC module adopts the DCBX specification to
implement the control state machine and three feature state machines:
•
Priority Group (PG)
•
Priority-based Flow Control (PFC)
•
Application Protocol (AP)
The following table lists the type of DCBX statistics displayed.
Item
Description
DCBX Application Protocol State
DCBX Overall Status
DCBX Pending Status
DCBX Priority Flow Control State
DCBX Priority Group State
DCBX Application Protocol State
The following table defines each statistic.
Item
Description
disabled
The feature is operationally disabled.
ok
The feature is configured properly or DCBX negotiation is in progress.
