Command line 80
Item
Description
port automatically disables port monitoring.
Syntax
remove port-monitor AnalyzerPort=
MonitorPort=
Properties
AnalyzerPort
The network analyzer port to be removed. Use "*" to remove all network analyzer
ports from the configuration.
MonitorPort
The monitor port to be removed. Use "*" to remove all monitor ports from the port
monitor configuration.
Examples
->remove port-monitor AnalyzerPort=enc0:3:1
Removes the network analyzer from the configuration
->remove port-monitor AnalyzerPort=*
Removes all network analyzer ports from the configuration
->remove port-monitor monitorPort=enc0:1:1
Removes a specific server port from the monitored port list
->remove port-monitor monitorPort=*
Removes all monitored ports
Item
Description
set port-monitor
Modify an existing port monitor configuration.
Syntax
set port-monitor [Enabled=
[AnalyzerPort=
[Speed=
[Duplex=
[Direction=
Properties
Enabled (optional) Enables or disables port monitoring. The network analyzer port must be configured
properly before port monitoring can be enabled.
AnalyzerPort
(optional)
The uplink port used for monitoring network traffic. The format of the network
analyzer port is
the enclosure ID is not specified, the default enclosure is the local enclosure.
Speed (optional)
The port speed for the network analyzer port. Valid values include "Auto",
"10Mb", "100Mb", "1Gb", "10Gb", and "Disabled". The default value is "Auto".
If there is no connector present on the analyzer port, only "Auto" and "Disabled"
can be configured as the port speed. Speed restrictions apply.
Duplex (optional)
The port duplex mode of the network analyzer port. Valid values include "Auto",
"Half", and "Full". The default value is "Auto".
MonitorPort
(required if the
Direction property
is being modified)
The server port to be monitored. The format of the monitored port is
specified, the default enclosure is the local enclosure where the domain resides.
Direction (optional) The direction of network traffic on the port being monitored. Valid values include
"ToServer", "FromServer", and "Both".
Examples
->set port-monitor AnalyzerPort=enc0:3:1 Speed=1Gb
Duplex=half
Modifies network analyzer uplink port properties
->set port-monitor MonitorPort=enc0:1:6 Direction=ToServer
Modifies a monitored server port
->set port-monitor Enabled=true
Enables port monitoring
