Command line 89
Item Description
Examples
->set qos-classifier Uplinks classifiers=DOT1P,DSCP
Configures uplink ports to use "DSCP" and "DOT1P" to prioritize the ingress
traffic
->set qos-classifier All classifiers=DOT1P
Configures all ports to use "DOT1P" to classify the ingress traffic
Item Description
show qos-classifier Display the QoS classifier configuration of the active QoS configuration
Syntax
show qos-classifier [ |*]
Parameter
PortType (optional) The type of port to which the classifiers are assigned. Valid values are "Uplinks"
and "Downlinks". If the port type is not specified, then classifiers for all port
types are displayed.
Examples
->show qos-classifier
Displays the classifier settings for both uplink and downlink ports
->show qos-classifier Uplinks
Displays the classifier settings for uplink ports
->show qos-classifier Downlinks
Displays the classifier settings for downlink ports
qos-map
Manage the traffic classification maps of the active QoS configuration.
Supported actions: help, set, show
Item Description
set qos-map Modify the traffic classification maps of the active QoS configuration
Syntax
set qos-map Class= Values=
DOT1P value range list>
Parameter
Type (required) The classifier type for the map. Valid values are "DOT1P" and "DSCP".
Properties
Class (required) The destination traffic class name. Values are mapped to the pre-defined
classes. A map is active if the map is currently in use for traffic classification. All
traffic classes in an active map must be enabled. A value in a map can be
mapped to one class only. An inactive map can have both enabled and
disabled classes.
Values (required) The list of DOT1P priority values or DSCP values for the map. The format is a
comma separated list of single values or hyphen-separated ranges. For a
DOT1P map, the supported DOT1P priority values are 0-7. The value 3 is
unique. Ingress non-FCoE traffic with a value of 3 is mapped to a user
configured traffic class. FCoE traffic (typically tagged with a DOT1P value of 3)
is always mapped to the FCoE_Lossless class, regardless of the map values. For
a DSCP map, the supported DSCP values are: AF11(DSCP 10),
AF12(DSCP12), AF13(DSCP 14), AF21(DSCP18), AF22(DSCP 20),
AF23(DSCP 22), AF31(DSCP 26), AF32(DSCP 28), AF33(DSCP 30),
AF41(DSCP 34), AF42(DSCP 36), AF43(DSCP 38), EF(DSCP 46), CS0(DSCP
0), CS1(DSCP 8), CS2 (DSCP 16), CS3(DSCP 24), CS4(DSCP 32), CS5(DSCP
