9
DESCRIPTION OF HART INTERFACE
190
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
I/O
I/O
terminals A Cust / terminals B Cust / terminals C Cust / terminals D Cust
A / B / C / D Opt current output Opt range 0% Cust / range 100% Cust / extended range min Cust /
extended range max Cust / error current Cust / error condition Cust /
measurement
Cust
/ range min
Cust
/ range max
Cust
/
polarity Cust / limitation min Cust / limitation max Cust /
lfc threshold Cust / lfc hysteresis Cust / time constant Cust /
special function Cust / rc threshold Opt, Cust / rc hysteresis Opt, Cust
frequency output Opt pulse shape Cust / pulse width Cust / 100% pulse rate Cust /
measurement
Cust
/
range min Cust / range max Cust /
polarity Cust / limitation min Cust / limitation max Cust /
lfc threshold Cust / lfc hysteresis Cust / time constant /
invert signal Cust / special function Opt, Cust /
phase shift w.r.t. B Opt, Cust
pulse output Opt pulse shape Cust / pulse width Cust / max pulse rate Cust / measurement
Cust /
pulse value unit / value p. pulse / polarity
Cust
/
lfc threshold Cust / lfc hysteresis Cust / time constant /
invert signal Cust / special function Opt, Cust /
phase shift w.r.t. B Opt, Cust
status output Opt mode / output A Opt / output B Opt / output C Opt /
output D
Opt
/ invert signal /
limit switch
Opt measurement / threshold / hysteresis / polarity
time constant / invert signal
control input Opt mode Cust / invert signal
counter counter 1
function Cust / measurement Opt /
lfc threshold Opt /
lfc hysteresis
Opt
/
time constant Opt / preset value Opt
counter 2
counter 3 Opt
Human machine interface
local display
language / default display
Opt
1. and 2. meas. page
function
Cust
/ measurement 1.line
Cust
/ range min
Cust
/ range max
Cust
/
limitation min / limitation max / lfc threshold / lfc hysteresis / time constant /
format 1.line / measurement 2.line
Cust / format 2.line Cust / measurement 3.line Cust /
format 3.line
Cust
graphic page select range / range centre / range +/- / time scale
units (device) unit for ...
volume flow
Cust
/ mass flow
Cust
/
flow speed / conductivity /
temperature / volume
Cust / mass Cust / density Cust
units (HART) unit for ... volume flow / mass flow /
flow speed / conductivity /
coil temperature / counter 1 / counter 2 / counter 3
Opt
formats (HART) format for ...
volume flow Loc / mass flow Loc /
flow speed Loc / conductivity Loc /
coil temperature
Loc
/ counter 1
Loc
/
counter 2 Loc / counter 3 Opt, Loc / diagnosis value Opt, Loc
