Device description, 2 wall-mounted housing – KROHNE IFC 300 Converter EN User Manual
Page 17
DEVICE DESCRIPTION
2
17
IFC 300
www.krohne.com
08/2010 - 4000069803 - MA IFC 300 R04 en
2.2.2 Wall-mounted housing
1 Turn lock to the right and open the cover.
Figure 2-4: Construction of wall-mounted housing
1 Cover for terminal compartments
2 Terminal compartment for measuring sensor
3 Terminal compartment for inputs and outputs
4 Terminal compartment for power supply with safety cover (shock-hazard protection)
5 Cable entry for signal cable
6 Cable entry for field current cable
7 Cable entry for inputs and outputs
8 Cable entry for power supply
