8
TECHNICAL DATA
146
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
Operating conditions
Temperature Temperature Temperature Temperature
Process temperature Refer to technical data for the measuring sensor.
Ambient temperature Depending on the version and combination of outputs.
It is a good idea to protect the converter from external heat sources such as direct
sunlight as higher temperatures reduce the life cycle of all electronic components.
-40…+65°C / -40…+149°F
Ambient temperatures below -25°C / -13°F, may affect the readability of the display.
Storage temperature -50…+70°C / -58…+158°F
Pressure Pressure Pressure Pressure
Medium Refer to technical data for the measuring sensor.
Ambient pressure Atmosphere: Height up to 2000 m / 6561.7 ft
Chemical properties Chemical properties Chemical properties Chemical properties
Electrical conductivity Standard Standard Standard Standard
All media except for water: ≥ 1 µS/cm
(also refer to the technical data for the measuring sensor)
Water: ≥ 20 µS/cm
TIDALFLUX 4000 TIDALFLUX 4000 TIDALFLUX 4000 TIDALFLUX 4000
All media: ≥ 50 µS/cm
(also refer to the technical data for the measuring sensor)
OPTIFLUX 7000 OPTIFLUX 7000 OPTIFLUX 7000 OPTIFLUX 7000
All media except for water: ≥ 0.05 µS/cm
(also refer to the technical data for the measuring sensor)
Water: ≥ 1 µS/cm
Physical condition Conductive, liquid media
Solid content (volume) Can be used up to ≤ 70% for OPTIFLUX and TIDALFLUX measuring sensors
The greater the solid content, the less accurate the measurements!
Gas content (volume) Can be used up to ≤ 5% for OPTIFLUX and TIDALFLUX measuring sensors
The greater the gas content, the less accurate the measurements!
Flow For detailed information, refer to chapter "Flow tables".
Other conditions Other conditions Other conditions Other conditions
Protection category acc. to
IEC 529 / EN 60529
C (compact version) & F (field housing):
IP66/67 (acc. to NEMA 4/4X/6)
W (wall-mounted housing):
IP65/66 (acc. to NEMA 4/4X)
R (19" rack-mounted housing (28 TE) or (21 TE)):
IP20 (acc. to NEMA 1);
Use: Indoor only, level of pollution 2 and relative humidity < 75%
Installation conditions
Installation For detailed information, refer to chapter "Installation conditions".
Inlet/outlet runs Refer to technical data for the measuring sensor.
Dimensions and weights For detailed information refer to chapter "Dimensions and weights".
