TECHNICAL DATA
8
153
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
Current input Current input Current input Current input
Function The following values can be delivered from the measuring sensor to the current
input: temperature, pressure or current
Operating data Basic I/Os Basic I/Os Basic I/Os Basic I/Os Modular I/Os Modular I/Os Modular I/Os Modular I/Os Ex i I/Os Ex i I/Os Ex i I/Os Ex i I/Os
Active - U
int, nom
= 24 VDC
I ≤ 22 mA
I
max
≤ 26 mA
(electronically limited)
U
0, min
= 19 V
at I ≤ 22 mA
No HART ®
U
int, nom
= 20 VDC
I ≤ 22 mA
U
0, min
= 14 V at I ≤ 22 mA
No HART ®
U
0
= 24.5 V
I
0
= 99 mA
P
0
= 0.6 W
C
0
= 75 nF / L
0
= 0.5 mH
No HART ®
Passive - U
ext
≤ 32 VDC
I ≤ 22 mA
I
max
≤ 26 mA
(electronically limited)
U
0, max
= 5 V
at I ≤ 22 mA
No HART ®
U
ext
≤ 32 VDC
I ≤ 22 mA
U
0, max
= 4 V at I ≤ 22 mA
No HART ®
U
i
= 30 V
I
i
= 100 mA
P
i
= 1 W
C
i
= 10 nF
L
i
= 0 mH
No HART ®
