DESCRIPTION OF HART INTERFACE
168
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
9.4 Inputs/outputs and HART ® dynamic variables and device variables
The signal converter is available with various in-/output combinations.
The connection of the terminals A…D to the HART ® dynamic variables PV, SV, TV and 4V depends
on the device version.
PV = Primary Variable; SV = Secondary Variable; TV = Third Variable; 4V = Fourth Variable
The signal converter can provide up to 10 measured values. The measured values are accessible
as so-called HART
® device variables and can be connected to the HART ® dynamic variables. The
availability of these variables depends on the device versions and the settings.
Code = device variable code
Device variables
Signal converter version
HART ® dynamic variable
PV SV TV 4V
Basic I/O, connection terminals A D - -
Modular I/O and Ex i I/O, connection terminals C D A B
HART ® device variable
Code Type Explanations
flow speed 20 linear
volume flow 21 linear
mass flow 22 linear
conductivity 24 linear
coil temperature 23 linear
counter 1 (C) 6 totalizer Valid for Basic I/O option only.
counter 1 (B) 13 totalizer Valid for Modular I/O and Ex i I/O options
only.
counter 2 (D) 14 totalizer
counter 3 (A) 12 totalizer Valid for Modular I/O and Ex i I/O options
only.
diagnosis value 25 linear Function and availability depends on
diagnosis value setting.
