6.3 Function tables
6.3.1 Menu A, quick setup
INFORMATION!
Depending on the device version, not all functions are available.
The description "PF option" used in the tables only refers to the TIDALFLUX 4000 measuring
sensor / "CAP option" only refers to the OPTIFLUX 7000 measuring sensor.
No.
Function
Settings / descriptions
A1 language
A1
language
Language selection depends on the device version.
A2 Tag
A2
Tag
Measuring point identifier (Tag no.) appears in the LC display header.
A3 reset
A3
reset
-
A3.1
reset errors
reset? Select: no/yes
A3.2
reset counter 1
reset counter? Select: no / yes (available if activated in C5.9.1)
A3.3
reset counter 2
reset counter? Select: no / yes (available if activated in C5.9.2)
A3.4
reset counter 3
reset counter? Select: no / yes (available if activated in C5.9.3)
A4 analogue outputs (only for HART
®
)
A4
analogue outputs
Applicable to all current outputs (terminals A, B and C), frequency outputs
(terminals A, B and D), limit switches (terminals A, B, C, and/or D) and the
1st display page / line 1.
A4.1
measurement
1) Select: volume flow / mass flow (not
not
not
not valid for PF (partly filled)) / diagnosis
value / flow speed / coil temperature / conductivity (not
not
not
not valid for PF (partly
filled)) and CAP (capacitive)) / level (only
only
only
only valid for PF (partly filled))
2) Use for all outputs? (also use this setting for Fct. A4.2...A4.5!)
Setting: no (applies only to the main current output ) / yes (applies to all
analogue outputs)
A4.2
unit
Selection of the unit from a list, depending on the measurement.
A4.3
range
1) Setting for main current output (range: 0...100%)
Setting: 0…x.xx (format and unit, depending on measurement, see A4.1 and
A4.2 above)
2) Use for all outputs? Make setting, see Fct. A4.1 above !
A4.4
low flow cutoff
1) Setting for main current output (sets output value to "0")
Setting: x.xxx ± x.xxx% (range: 0.0…20%)
(1st value = switching point / 2nd value = hysteresis),
condition: 2nd value ≤ 1st value
2) Use for all outputs? Make setting, see Fct. A4.1 above !
A4.5
time constant
1) Setting for main current output (applicable to all flow measurements)
Setting: xxx.x s (range: 000.1…100 s)
2) Use for all outputs? Make setting, see Fct. A4.1 above !
