6
OPERATION
114
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
B3.4 flow fraction Only Only Only Only valid for PF option (partly filled)!
Simulation of the flow fraction for partly filled pipes. This value is multiplied
with the normal flow measurement. 100% relates to fully filled pipes.
Sequence and settings similar to B1.1, see above!
B1.8 level Only Only Only Only valid for PF option (partly filled)!
Simulation of the level for partly filled pipes.
Sequence and settings similar to B1.1, see above!
B2 actual values
B2 actual values Display the current values; exit the displayed function with key ^.
B2.1 operating hours Display the actual operating hours; exit the displayed function with key ^.
B2.2 act. flow speed Display the actual flow speed; exit the displayed function with key ^.
B2.3 act. coil temp. See also Fct. C1.1.7...C1.1.8
B2.4 electr. temperature Display the actual electronics temperature; exit the displayed function with
key ^.
B2.5 act. conductivity See also Fct. C1.3.1...C1.3.2
With the CAP option (capacitive) and the PF option (partly filled) this
measurement is only used for empty pipe detection (Fct. C1.1.10).
B2.6 act. electr. noise See also Fct. C1.3.13...C1.3.15
B2.7 act. flow profile Not Not Not Not valid for PF option (partly filled)!
See also Fct. C1.1.10...C1.1.12
B2.8 act. coil resistance Display the actual resistance of the field coils depending on the current coil
temperature.
B2.9 current input A Displays the active current value.
B2.10 current input B
B2.11 flow fraction Only Only Only Only valid for PF option (partly filled)!
Display of the actual flow fraction for partly filled pipes. This value is
multiplied with the normal flow measurement. 100% relates to fully filled
pipes.
B2.12 level Only Only Only Only valid for PF option (partly filled)!
Display of the actual level for partly filled pipes.
B3 information
B3 information -
B3.1 C number CG number, non-alterable (I/O version)
B3.2 process input Process input section
LC display:
1st line: ID No. of the circuit board
2nd line: software version
3rd line: production date
B3.3 SW.REV.MS
Electronics and HART ® software.
LC display:
1st line: ID No. of the circuit board
2nd line: software version
3rd line: production date
No. Function Settings / descriptions
