TECHNICAL DATA
8
147
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
Materials
Signal converter housing Standard Standard Standard Standard
Version C and F: die-cast aluminium (polyurethane coated)
Version W: polyamide - polycarbonate
Version R (28 TE): Aluminium, stainless steel and aluminium sheet, partially
polyester-coated
Version R (21 TE): Aluminium and aluminium sheet, partially polyester-coated
Option Option Option Option
Versions C and F: Stainless steel 316 L (1.4408)
Measuring sensor For housing materials, process connections, liners, grounding electrodes and
gaskets, refer to technical data for the measuring sensor.
Electrical connection
General Electrical connection is carried out in conformity with the VDE 0100 directive
"Regulations for electrical power installations with line voltages up to 1000 V" or
equivalent national regulations.
Power supply Standard: 100…230 VAC (-15% / +10%), 50/60 Hz
240 VAC + 5% is included in the tolerance range.
Option 1: 12...24 VDC (-55% / +30%)
12 VDC - 10% is included in the tolerance range.
Option 2: 24 VAC/DC (AC: -15% / +10%, 50/60 Hz; DC: -25% / +30%)
12 V is not not not not included in the tolerance range.
Power consumption AC: 22 VA
DC: 12 W
Signal cable Only for remote versions.
DS 300 (type A) DS 300 (type A) DS 300 (type A) DS 300 (type A)
Max. length: 600 m / 1968 ft (depending on electrical conductivity and measuring
sensor version)
BTS 300 (type B) BTS 300 (type B) BTS 300 (type B) BTS 300 (type B)
Max. length: 600 m / 1968 ft (depending on electrical conductivity and measuring
sensor version)
Type LIYCY (only FM, Class 1 Div. 2) Type LIYCY (only FM, Class 1 Div. 2) Type LIYCY (only FM, Class 1 Div. 2) Type LIYCY (only FM, Class 1 Div. 2)
Max. length: 100 m / 328 ft (depending on electrical conductivity and measuring
sensor version)
Interface cable
(only TIDALFLUX)
Type LIYCY Type LIYCY Type LIYCY Type LIYCY
Max. length: 600 m / 1968 ft (3 x 0.75 mm
2
shielded cable)
Cable entries (except
TIDALFLUX)
Standard: M20 x 1.5 (8...12 mm) for C, F and W version;
Terminal strip for R-version
Option: ½" NPT, PF ½ for C, F and W version
Cable entries (only TIDALFLUX) Standard:
Converter: 2 x M20 x 1.5 metal + 1 x M20 x 1.5 EMC metal
Sensor: 2 x M20 x 1.5 plastic + 1 x M16 x 1.5 EMC metal
Option: NPT
