No. Function Settings / descriptions
C4 I/O HART
C4 I/O HART
Selection / display of the 4 dynamic variables (DV) for HART ® .
The HART ® current output (terminal A basic I/Os or terminal C modular I/Os)
always has a fixed link to the primary variables (PV). Fixed links of the other
DVs (1-3) are only possible if additional analogue outputs (current and
frequency) are available; if not, the measurement can be freely selected
from the following list: in Fct. A4.1 "measurement".
stands for 1, 2, 3 or 4
X stands for connection terminals A...D
C4.1 PV is Current output (primary variable)
C4.2 SV is (secondary variable)
C4.3 TV is (tertiary variable)
C4.4 4V is (4th variable)
C4.5 HART units Changes units of DVs (dynamic variables) in the display
Break: return with ^ key
HART display ® : copies the settings for the display units to the settings for
DVs
Standard: sets factory defaults for DVs
C4. .1 current out X Shows the current analogue measured value of the linked current output.
The measurement cannot be changed!
C4. .1 frequency out X Shows the current analogue measured value of the linked frequency output,
if present. The measurement cannot be changed!
C4. .1 HART dynamic var.
Measurements of the dynamic variables for HART ® .
Linear measurements: volume flow / mass flow (not not not not valid for PF (partly
filled)) / diagnosis value / flow speed / coil temperature / conductivity (not not not not
valid for PF (partly filled) and CAP (capacitive)) / level (only only only only valid for PF
(partly filled))
Digital measurements: counter 1 / counter 2 / counter 3 / operating hours
No. Function Settings / descriptions
C5 device
C5.1 device info
C5.1 device info Grouping of all functions that have no direct effect on the measurement or
any output.
C5.1.1 Tag Settable characters (max. 8 digits):
A…Z; a…z; 0…9; / - , .
C5.1.2 C number CG number, non-alterable (input/output versions)
C5.1.3 device serial no. Serial no. of the system.
C5.1.4 electronic serial no. Serial no. of the electronic assembly, cannot be changed.
C5.1.5 SW.REV.MS Serial no. of the circuit board, version no. of the main software, production
date of the circuit board
C5.1.6 Electronic Revision ER Reference identification number, electronic revision and production date of
the device; includes all hardware and software changes
