OPERATION
6
115
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
6.3.3 Menu C, setup
B3.4 SW.REV.UIS User interface
LC display:
1st line: ID No. of the circuit board
2nd line: software version
3rd line: production date
B3.5 "bus interface" Only appears with Profibus, Modbus and FF.
LC display:
1st line: ID No. of the circuit board
2nd line: software version
3rd line: production date
B3.6 Electronic Revision ER Shows ID no., electronic revision no. and production date;
Contains all hardware and software changes.
No. Function Settings / descriptions
C1 process input
C1.1 calibration
C1.1 calibration Grouping of all functions related to measuring sensor calibration.
C1.1.1 zero calibration Display of actual zero calibration value.
Query: calibrate zero?
Setting: break (return with ^ key) /
standard (with factory setting) /
manual (display last value, set new value, range: -1.00…+1 m/s) /
range: -1.00…+1 m/s) /
automatic (shows the current value as the new zero calibration value)
C1.1.2 size Select from size table.
C1.1.3 GK selection Not Not Not Not valid for PF option (partly filled)!
Select the field current and the active GKx values; select GK value (see
nameplate of the measuring sensor).
Select: GK & GKL (both values possible / linearity test) /
GK (250 mApp) (only GK values possible) /
GKL (125 mApp) (only GKL values possible) /
GKH (250 mApp) (only GKH values possible)
C1.1.4 GK Depending on the selection in Fct. C1.1.3, Fct. C1.1.4 appears.
Set value acc. to nameplate; range: 0.5…12 (20)
C1.1.5 GKL Not Not Not Not valid for PF option (partly filled)!
Depending on the selection in Fct. C1.1.3, Fct. C1.1.5 appears.
Set value acc. to nameplate; range: 0.5…12 (20)
C1.1.6 GKH Not Not Not Not valid for PF option (partly filled)!
Depending on the selection in Fct. C1.1.3, Fct. C1.1.6 appears.
Set value acc. to nameplate; range: 0.5…12 (20)
C1.1.7 coil resistance Rsp Field coil resistance at 20°C; range: 10.00...220 Ω
