Operation – KROHNE IFC 300 Converter EN User Manual
Page 132
6
OPERATION
132
IFC 300
www.krohne.com
08/2010 - 4000069803 - MA IFC 300 R04 en
C5.7 units
C5.7
units
-
C5.7.1
volume flow
m³/h; m³/min; m³/s; l/h; l/min; l/s (l = litres);
ft³/h; ft³/min; ft³/s; gal/h; gal/min; gal/s;
IG/h; IG/min; IG/s; cf/h; cf/min; cf/s;
free unit (set factor and text in the next two functions, sequence see below)
C5.7.2
Text free unit
For text to be specified refer to
Set free units
on page 133:
C5.7.3
[m³/s]*factor
Specification of the conversion factor, based on m³/s:
xxx.xxx refer to
Set free units
on page 133
C5.7.4
mass flow
kg/s; kg/min; kg/h; t/min; t/h; g/s; g/min; g/h;
lb/s; lb/min; lb/h; ST/min; ST/h (ST = Short Ton); LT/h (LT = Long Ton);
free unit (set factor and text in the next two functions, sequence see below)
C5.7.5
Text free unit
For text to be specified refer to
Set free units
on page 133:
C5.7.6
[kg/s]*factor
Specification of the conversion factor, based on kg/s:
xxx.xxx refer to
Set free units
on page 133
C5.7.7
flow speed
m/s; ft/s
C5.7.8
conductivity
µ
S/cm; S/cm
C5.7.9
temperature
°
C; °F; K
C5.7.10
volume
m³; l (Liter); hl; ml; gal; IG; in³; ft³; yd³; cf;
free unit (set factor and text in the next two functions, sequence see below)
C5.7.11
Text free unit
For text to be specified refer to
Set free units
on page 133:
C5.7.12
[m³]*factor
Specification of the conversion factor, based on m³:
xxx.xxx refer to
Set free units
on page 133
C5.7.13
mass
kg; t; mg; g; lb; ST; LT; oz;
free unit (set factor and text in the next two functions, sequence see below)
C5.7.14
Text free unit
For text to be specified refer to
Set free units
on page 133:
C5.7.15
[kg]*factor
Specification of the conversion factor, based on kg:
xxx.xxx refer to
Set free units
on page 133
C5.7.16
density
kg/l; kg/m³; lb/cf; lb/gal;
free unit (set factor and text in the next two functions, sequence see below)
C5.7.17
Text free unit
For text to be specified refer to
Set free units
on page 133:
C5.7.18
[kg/m³]*factor
Specification of the conversion factor, based on kg/m³:
xxx.xxx refer to
Set free units
on page 133
C5.7.19
pressure
Pa; kPa; bar; mbar; psi (no free units possible);
only if current input available.
