8
TECHNICAL DATA
154
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
PROFIBUS DP PROFIBUS DP PROFIBUS DP PROFIBUS DP
Description Galvanically isolated acc. to IEC 61158
Profile version: 3.01
Automatic data transmission rate recognition (max. 12 MBaud)
Bus address adjustable via local display at the measuring device
Function blocks 5 x analogue input, 3 x totaliser
Output data Volume flow, mass flow, volume counter 1 + 2, mass counter, velocity, coil
temperature, conductivity
PROFIBUS PA PROFIBUS PA PROFIBUS PA PROFIBUS PA
Description Galvanically isolated acc. to IEC 61158
Profile version: 3.01
Current consumption: 10.5 mA
Permissible bus voltage: 9…32 V; in Ex application: 9...24 V
Bus interface with integrated reverse polarity protection
Typical error current FDE (Fault Disconnection Electronic): 4.3 mA
Bus address adjustable via local display at the measuring device
Function blocks 5 x analogue input, 3 x totaliser
Output data Volume flow, mass flow, volume counter 1 + 2, mass counter, velocity, coil
temperature, conductivity
FOUNDATION Fieldbus FOUNDATION Fieldbus FOUNDATION Fieldbus FOUNDATION Fieldbus
Description Galvanically isolated acc. to IEC 61158
Current consumption: 10.5 mA
Permissible bus voltage: 9…32 V; in Ex application: 9...24 V
Bus interface with integrated reverse polarity protection
Link Master function (LM) supported
Tested with Interoperable Test Kit (ITK) version 5.1
Function blocks 3 x analogue Input, 2 x integrator, 1 x PID
Output data Volume flow, mass flow, velocity, coil temperature, conductivity, electronics
temperature
Modbus Modbus Modbus Modbus
Description Modbus RTU, Master / Slave, RS485
Address range 1…247
Supported function codes 03, 04, 16
Broadcast Supported with function code 16
Supported Baudrate 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 Baud
