6
OPERATION
120
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
C1.5 simulation
C1.5 simulation Grouping of all functions for simulating measuring sensor values. These
simulations have effect on all outputs, including counters and display.
C1.5.1 flow speed Sequence see Fct. B1.1
C1.5.2 volume flow Sequence see Fct. B1.2
C1.5.3 flow fraction Only Only Only Only valid for PF option (partly filled)!
Sequence see Fct. B1.3
C1.5.4 level Only Only Only Only valid for PF option (partly filled)!
Sequence see Fct. B1.4
No. Function Settings / descriptions
C2 I/O (Inputs/Outputs)
C2.1 hardware
C2.1 hardware Assignment of connection terminals dependent on signal converter version:
active / passive / NAMUR
C2.1.1 terminal A Select: off (switched off) / current output / frequency output / pulse output /
status output / limit switch / control input / current input
C2.1.2 terminal B Select: off (switched off) / current output / frequency output / pulse output /
status output / limit switch / control input / current input
C2.1.3 terminal C Select: off (switched off) / current output / status output / limit switch
C2.1.4 terminal D Select: off (switched off) / frequency output / pulse output / status output /
limit switch
