TECHNICAL DATA
8
145
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
Options Options Options Options
Outputs / inputs Current (incl. HART®), pulse, frequency and/or status output, limit switch and/or
control input or current input (depending on the I/O version)
Totalizer 2 (optional 3) internal counters with a max. of 8 counter places (e.g. for counting
volume and/or mass units)
Verification Integrated verification, diagnostic functions: measuring device, process, measured
value, empty pipe detection, stabilization
Communication interfaces
Foundation Fieldbus, Profibus PA and DP, Modbus, HART ®
Display and user interface Display and user interface Display and user interface Display and user interface
Graphic display LC display, backlit white.
Size: 128 x 64 pixels, corresponds to 59 x 31 mm = 2.32" x 1.22"
Display can be rotated in 90° increments.
Ambient temperatures below -25°C / -13°F, may affect the readability of the display.
Operating elements 4 optical keys for operator control of the signal converter without opening the
housing.
Infrared interface for reading and writing all parameters with IR interface (option)
without opening the housing.
Remote control
PACTware ® (incl. Device Type Manager (DTM))
HART ® Hand Held Communicator from Emerson Process
AMS ® from Emerson Process
PDM ® from Siemens
All DTMs and drivers are available free of charge from the manufacturer's website.
Display functions Display functions Display functions Display functions
Operating menu Setting the parameters using 2 measured value pages, 1 status page, 1 graphics
page (measured values and graphics are freely adjustable)
Language display texts (as
language package)
Standard: English, French, German, Dutch, Portuguese, Swedish, Spanish, Italian
Eastern Europe: English, Slovenian, Czech, Hungarian
Northern Europe: English, Danish, Polish
China: English, German, Chinese
Russia: English, German, Russian
Units Metric, British and US units selectable as required from lists for volume / mass flow
and counting, flow velocity, electrical conductivity, temperature, pressure
Measuring accuracy
Reference conditions Depending on the measuring sensor version.
Refer to technical data for the measuring sensor.
Maximum measuring error ± 0.15% of the measured value ±1 mm/s, depending on the measuring sensor
For detailed information and accuracy curves, refer to chapter "Accuracy".
Current output electronics: ±5 µA
Repeatability ± 0.06% acc. to OIML R117;
Not valid for WATERFLUX 3000, OPTIFLUX 7000 and TIDALFLUX 4000
