DESCRIPTION OF HART INTERFACE
182
IFC 300
www.krohne.com
08/2010 - 4000069803 - MA IFC 300 R04 en
I/O terminals
A/B/C/D
current output
Opt
range 0%
Cust
/ range 100%
Cust
/
extended range min
Cust
/ extended range max
Cust
/
error current
Cust
/ error condition
Cust
/
measurement
Cust
/ range min
Cust
/
range max
Cust
/ polarity
Cust
/
limitation min
Cust
/ limitation max
Cust
/
lfc threshold
Cust
/ lfc hysteresis
Cust
/
time constant
Cust
/ special function
Cust
/
rc threshold
Opt, Cust
/ rc hysteresis
Opt, Cust
frequency output
Opt
pulse shape
Cust
/ pulse width
Cust
/
100% pulse rate
Cust
/ measurement
Cust
/
range min
Cust
/ range max
Cust
/
polarity
Cust
/ limitation min
Cust
/
limitation max
Cust
/ lfc threshold
Cust
/
lfc hysteresis
Cust
/ time constant
Cust
/
invert signal
Cust
/ special function
Opt, Cust
/
phase shift w.r.t. B
Opt, Cust
pulse output
Opt
pulse shape
Cust
/ pulse width
Cust
/
max. pulse rate
Cust
/ measurement
Cust
/
pulse value unit / value p. pulse /
polarity
Cust
/ lfc threshold
Cust
/
lfc hysteresis
Cust
/ time constant /
invert signal
Cust
/ special function
Opt, Cust
/
phase shift w.r.t. B
Opt, Cust
status output
Opt
mode / output A
Opt
/
output B
Opt
/ output C
Opt
/
output D
Opt
/ invert signal
limit switch
Opt
measurement / threshold / hysteresis /
polarity / time constant /
invert signal
control input
Opt
mode
Cust
/ invert signal
counter
counter 1
function
Cust
/ measurement
Opt, Cust
/
lfc threshold
Opt, Cust
/ lfc hysteresis
Opt, Cust
/
time constant
Opt, Cust
/ preset value
Opt, Cust
counter 2
counter 3
Opt
device
device info
tag / C number
Rd
/ device serial no.
Rd
/
electronic serial no.
Rd
display
language / default display
Cust
units
volume flow
Cust
/ mass flow
Cust
/
flow speed
Cust
/ conductivity
Cust
/
temperature
Cust
/ volume
Cust
/
mass
Cust
/ density
Cust
1. and 2. meas. page
graphic page
1. and 2. meas. page
function
Cust
/ measurement 1.line
Cust
/
range min
Cust
/ range max
Cust
/
limitation min / limitation max /
lfc threshold / lfc hysteresis /
time constant / format 1.line /
measurement 2.line
Cust
/ format 2.line
Cust
/
measurement 3.line
Cust
/ format 3.line
Cust
graphic page
select range / range centre /
range +/- / time scale
