6.1.5 Using an IR interface (option)
The optical IR interface serves as an adapter for PC-based communication with the signal
converter without opening the housing.
Time-out function
Following activation of the IR interface in Fct. A6 or C5.6.6 the interface must be properly
positioned and attached to the housing with the suction cups within 60 seconds. If this does not
happen within the specified time period, the device can be operated using the optical keys again.
Upon activation, the LED 3 lights up and the optical keys no longer function.
INFORMATION!
• This device is not part of the scope of delivery.
• For more information about activation with the functions A6 or C5.6.6 refer to Function tables
on page 111
.
Figure 6-6: IR interface
1 Glass panel in front of the control and display panel
2 IR interface
3 LED lights up when IR interface is activated.
4 Suction cups
