DESCRIPTION OF HART INTERFACE
9
183
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
HART identification
manufacturer Rd / model Rd / device ID Rd /
address / tag / date / message / description /
write protect
Rd / final assembly no. / sensor serial no.
revision numbers
universal rev. Rd / device rev. Rd /
software rev. Rd / hardware rev. Rd
preambles
request preams Rd / response preams
dynamic variables
PV is Rd / SV is / TV is / 4V is
HART units display formats
volume flow Loc / mass flow Loc /
flow speed Loc / conductivity Loc /
temperature
Loc
/ counter 1
Loc
/ counter 2
Loc
/
counter 3 Opt, Loc / diagnosis value Opt, Loc
units volume flow / mass flow /
flow speed / conductivity /
temperature / counter 1 / counter 2 / counter 3
Opt
Compare and Clear Offline
Status
Overview Standard Primary variable out of limits
Non-primary variable out of limits
Primary variable analogue output saturated
Primary variable analogue output fixed
Cold start
Field device malfunction
Configuration changed
Failure (device) F error in device / F IO1 / F parameter / F IO2 / F configuration / F display /
F sensor electronic / F sensor global / F sensor local / F field current local /
F current in-/output A / F current in-/output B / F current output C /
F software user interface / F hardware settings / F hardware detection /
F RAM/ROM error IO1 / F RAM/ROM error IO2
Failure (application) F application error / F empty pipe / F flow rate too high / F field frequency too high /
F DC offset / F open circuit A / F open circuit B / F open circuit C /
F over range A (current) / F over range B (current) / F over range C (current) /
F over range A (pulse) / F over range B (pulse) / F over range C (pulse) /
F active settings / F factory settings / F backup 1 settings /
F backup 2 settings
Out of specification S out of specification / S pipe not full / S pipe empty / S linearity /
S flow profile / S electrode noise / S gain error /
S electrode symmetry / S field coil broken / S field coil bridged /
S field current deviation / S field frequency too high / S electronic temperature /
S coil temperature / S overflow counter 1 / S overflow counter 2 /
S overflow counter 3 / S backplane invalid
Check request &
Information
check request C checks in progress / C test sensor
information I counter 1 stopped / I counter 2 stopped /
I counter 3 stopped / I power fail /
I control input A active / I control input B active /
I over range display 1 / I over range display 2 /
I backplane sensor / I backplane settings /
I backplane difference / I optical interface
