9
DESCRIPTION OF HART INTERFACE
176
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
9.11.2 Basic-DD menu tree (details for settings)
1 dynam. variable
1 measured values 1 volume flow / 2 mass flow / 3 flow speed /
4 conductivity / 5 coil temperature / 6 counter 1
Opt / 7 counter 2 Opt /
8 counter 3 Opt / 9 diagnosis value Opt
2 Inputs/Outputs
1 A Opt / 2 % range A Opt / 3 B Opt / 4 % range B Opt / 5 C Opt /
6 % range C
Opt
/ 7 D
Opt
/ 8 % range D
Opt
2 quick setup
1 language -
2 tag -
3 reset
1 reset errors / 2 reset counter 1 Opt /
3 reset counter 2
Opt
/ 4 reset counter 3
Opt
4 analogue outputs
1 measurement A/C
Cust
/ 2 unit
Cust
/ 3 range min A/C
Cust
/
4 range max A/C Cust / 5 lfc threshold Cust / 6 lfc hysteresis Cust /
7 time constant Cust
5 digital outputs
1 measurement D Opt, Cust / 2 pulse value unit Opt, Cust /
3 value p. pulse D Opt, Cust / 4 lfc threshold Opt, Cust / 5 lfc hysteresis Opt, Cust
3 test
1 simulation
1 simul. current / frequency A Opt / 2 simul. current / frequency B Opt /
3 simul. current C Opt / 4 simul. frequency D
2 information 1 C number / 2 info process input / 3 info device / 4 info display
4 setup
1 process input 1 calibration
1 autom. zero calib. Cust / 2 zero calibration Cust /
3 size Cust / 4 GK selection Cust /
5 GK / GKH
Opt, Cust
/ 6 GKL
Opt, Cust
/
7 coil resistance Rsp Cust / 8 density Cust /
9 target conduct. Cust / 10 EF electr. factor Cust /
11 num. of electrodes Cust / 12 field frequency Cust /
13 select settling
Cust
/ 14 settling time
Opt Cust
/
15 line frequency Cust
2 filter
1 limitation min Cust / 2 limitation max Cust /
3 flow direction Cust / 4 time constant /
5 pulse filter Cust / 6 pulse width Opt, Cust /
7 pulse limitation
Opt, Cust
/ 8 noise filter
Cust
/
9 noise level Opt, Cust / 10 noise suppression Opt, Cust /
11 lfc threshold Cust / 12 lfc hysteresis Cust
3 self test
1 empty pipe Cust / 2 limit empty pipe Opt, Cust /
3 full pipe
Opt, Cust
/ 4 limit full pipe
Opt, Cust
/
5 linearity Cust / 6 gain Cust /
7 coil current Cust / 8 flow profile Cust /
9 limit flow profile Opt, Cust /
10 electrode noise
Cust
/
11 limit electr. noise Opt, Cust /
12 settling of field Cust /
13 diagnosis value Rd / 14 select diagnosis
