Inputs and outputs
General All outputs are electrically isolated from each other and from all other circuits.
All operating data and output values can be adjusted.
Description of used abbreviations U
ext
= external voltage; R
L
= load + resistance;
U
o
= terminal voltage; I
nom
= nominal current
Safety limit values (Ex i):
U
i
= max. input voltage; I
i
= max. input current; P
i
= max. input power rating; C
i
=
max. input capacity; L
i
= max. input inductivity
Current output Current output Current output Current output
Output data Volume flow, mass flow, diagnostic value, flow velocity, coil temperature,
conductivity
Settings Without HART Without HART Without HART Without HART ®
Q = 0%: 0…15 mA; Q = 100%: 10…20 mA
Error identification: 3…22 mA
With HART With HART With HART With HART ®
Q = 0%: 4…15 mA; Q = 100%: 10…20 mA
Error identification: 3.5…22 mA
Operating data Basic I/Os Basic I/Os Basic I/Os Basic I/Os Modular I/Os Modular I/Os Modular I/Os Modular I/Os Ex i I/Os Ex i I/Os Ex i I/Os Ex i I/Os
Active U
int, nom
= 24 VDC
I ≤ 22 mA
R
L
≤ 1 kΩ
U
int, nom
= 20 VDC
I ≤ 22 mA
R
L
≤ 450 Ω
U
0
= 21 V
I
0
= 90 mA
P
0
= 0.5 W
C
0
= 90 nF / L
0
= 2 mH
C
0
= 110 nF / L
0
= 0.5 mH
Linear characteristics
Passive U
ext
≤ 32 VDC
I ≤ 22 mA
U
0
≥ 1.8 V
R
L
≤ (U
ext
- U
0
) / I
max
U
ext
≤ 32 VDC
I ≤ 22 mA
U
0
≥ 4 V
R
L
≤ (U
ext
- U
0
) / I
max
U
i
= 30 V
I
i
= 100 mA
P
i
= 1 W
C
i
= 10 nF
L
i
~ 0 mH
