9
DESCRIPTION OF HART INTERFACE
178
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
3 I/O counter 1 counter 1
1 funct. of counter Cust / 2 measurement Cust /
3 select measurement Opt, Cust / 4 lfc threshold Cust /
5 lfc hysteresis Cust / 6 time constant Cust /
7 preset value Opt, Cust / 8 reset counter Opt, Cust /
9 set counter Opt, Cust / 10 information
2 counter 2
3 counter 3 Opt
4 I/O HART
1 PV is Rd / 2 SV is / 3 TV is / 4 4V is / 5 D/A trim Cust / 6 apply values Cust
5 device 1 device info
1 tag / 2 C number Rd / 3 device serial no. Rd /
4 electronic serial no. Rd / 5 SW.REV.MS /
6 circuit board info
2 display 1 language / 2 default display / 3 SW.REV.UIS
3 1. meas. page
4 2. meas. page
1 function Cust / 2 measurement 1.line Cust /
3 range min Cust / 4 range max Cust /
5 limitation min / 6 limitation max /
7 lfc threshold / 8 lfc hysteresis /
9 time constant / 10 format 1.line /
11 measurement 2.line
Cust / 12 format 2.line Cust /
13 measurement 3.line Cust / 14 format 3.line Cust
5 graphic page 1 select range / 2 range centre /
3 range +/- / 4 time scale
6 special functions 1 list errors / 2 reset errors / 3 warmstart
7 units (device)
1 volume flow
Cust
/ 2 mass flow
Cust
/
3 flow speed Cust / 4 conductivity Cust /
5 temperature Cust / 6 volume Cust /
7 mass
Cust
/ 8 density
Cust
8 HART 1 address
2 message
3 description
4 units (HART) 1 volume flow
5 formats (HART) 2 mass flow
3 flow speed
4 conductivity
5 temperature
6 counter 1
7 counter 2
8 counter 3 Opt
9 diagnosis value
