DEVICE DESCRIPTION
2
15
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
2.2 Device description
Electromagnetic flowmeters are designed exclusively to measure the flow and conductivity of
electrically conductive, liquid media.
Your measuring device is supplied ready for operation. The factory settings for the operating
data have been made in accordance with your order specifications.
The following versions are available:
• Compact version (the signal converter is mounted directly on the measuring sensor)
• Remote version (electrical connection to the measuring sensor via field current and signal
cable)
Figure 2-2: Device versions
1 Compact version
2 Measuring sensor with connection box
3 Field housing
4 Wall-mounted housing
5 19" rack-mounted housing
