8.2 Technical data
INFORMATION!
• The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local representative.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Download Center).
Measuring system
Measuring principle Faraday's law of induction
Application range Continuous measurement of current volume flow, flow velocity, conductivity, mass
flow (at constant density), coil temperature of the measuring sensor
Design
Modular design The measuring system consists of a measuring sensor and a signal converter.
Measuring sensor Measuring sensor Measuring sensor Measuring sensor
OPTIFLUX 1000 DN10...150 / 3/8…6"
OPTIFLUX 2000 DN25...3000 / 1…120"
OPTIFLUX 4000 DN2.5...3000 / 1/10…120"
OPTIFLUX 5000 Flange: DN15...300 / ½…12"
Sandwich: DN2.5...100 / 1/10…4"
OPTIFLUX 6000 DN2.5...150 / 1/10…6"
OPTIFLUX 7000 Flange: DN25...100 / 1…4"
Sandwich: DN25...100 / 1…4"
This capacitive flowmeter is only available as compact version (OPTIFLUX 7300 C).
WATERFLUX 3000 DN25...600 / 1...24"
TIDALFLUX 4000 DN200...1600 / 8...64"
This sensor for measurements in partly filled pipelines is only available as a remote
field housing version (TIDALFLUX 4300 F).
With the exception of the OPTIFLUX 1000, TIDALFLUX 4000 and WATERFLUX 3000
all measuring sensors are also available as Ex versions.
Signal converter Signal converter Signal converter Signal converter
Compact version (C) OPTIFLUX x300 C (x = 1, 2, 4, 5, 6, 7) or WATERFLUX 3300 C
Field housing (F) -
remote version
IFC 300 F
Wall-mounted housing (W) -
remote version
IFC 300 W
Compact and field housing versions are also available as Ex versions.
19" rack-mounted housing (R) -
remote version
IFC 300 R
