DESCRIPTION OF HART INTERFACE
9
177
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
4 information 1 liner / 2 electr. material /
3 serial no. sensor
Rd
/ 4 V no. sensor
Rd
/
5 sensor electr. info
5 sensor limits 1 volume flow
1 upper snsr limit Rd /
2 lower snsr limit Rd /
3 minimum span
Rd
2 mass flow
3 flow speed
4 conductivity
5 coil temperature
2 I/O 1 hardware
1 terminals A
Cust
/ 2 terminals B
Cust
/
3 terminals C Cust / 4 terminals D Cust
2 A
3 B
4 C
5 D
current output current output current output current output Opt Opt Opt Opt :
1 range 0% Cust / 2 range 100% Cust /
3 extended range min Cust / 4 extended range max Cust /
5 error current
Cust
/ 6 error condition
Cust
/
7 measurement Cust / 8 range min Cust /
9 range max Cust / 10 polarity Cust /
11 limitation min Cust / 12 limitation max Cust /
13 lfc threshold
Cust
/ 14 lfc hysteresis
Cust
/
15 time constant Cust / 16 special function Cust /
17 rc threshold Opt, Cust / 18 rc hysteresis Opt, Cust /
19 information
frequency output frequency output frequency output frequency output
Opt Opt Opt Opt
:
1 pulse shape Cust / 2 pulse width Cust /
3 100% pulse rate Cust / 4 measurement Cust /
5 range min Cust / 6 range max Cust /
7 polarity Cust / 8 limitation min Cust /
9 limitation max Cust / 10 lfc threshold Cust /
11 lfc hysteresis Cust / 12 time constant Cust /
13 invert signal
Cust
/ 14 special function
Opt, Cust
/
15 phase shift w.r.t. B Opt, Cust / 16 information
pulse output pulse output pulse output pulse output Opt Opt Opt Opt :
1 pulse shape Cust / 2 pulse width Cust /
3 max. pulse rate Cust / 4 measurement Cust /
5 pulse value unit / 6 value p. pulse /
7 polarity
Cust / 8 lfc threshold Cust /
9 lfc hysteresis Cust / 10 time constant /
11 invert signal
Cust
/ 12 special function
Opt, Cust
/
13 phase shift w.r.t. B Opt, Cust / 14 information
status output status output status output status output Opt Opt Opt Opt :
1 mode / 2 output A Opt /
2 output B Opt / 2 output C Opt /
2 output D
Opt
/ 3 invert signal /
4 information
limit switch limit switch limit switch limit switch Opt Opt Opt Opt :
1 measurement / 2 threshold / 3 hysteresis /
4 polarity / 5 time constant /
6 invert signal / 7 information
control input control input control input control input Opt Opt Opt Opt :
1 mode
Cust
/ 2 invert signal /
3 information
