9
DESCRIPTION OF HART INTERFACE
188
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
Menu View
display volume flow / mass flow / flow speed / conductivity / coil temperature / diagnosis value / device
status
counter
counter 1 Opt / counter 2 Opt / counter 3 Opt /
Yt diagram
volume flow
Opt
/ mass flow
Opt
outputs
current output /frequency output A
Opt
measured value
Opt
/
A Opt /
% range A Opt
current output/frequency output B Opt measured value Opt /
B Opt /
% range B Opt
current output C Opt measured value Opt /
C Opt /
% range C Opt
frequency output D Opt measured value Opt /
D Opt /
% range D Opt
Device Status device
C number Rd / device serial no. Rd / electronic serial no. Rd
HART
tag / manufacturer
Rd
/ write protect
Rd
/
model Rd / device ID / universal rev. Rd /
device rev. Rd / software rev. Rd / hardware rev. Rd /
date Rd / final assembly no. Rd / sensor serial no. Rd
Standard (overview) Primary variable out of limits
Non-primary variable out of limits
Primary variable analogue output saturated
Primary variable analogue output fixed
Cold start
Configuration changed
Field device malfunction
Failure (device) F error in device / F IO1 / F parameter / F IO2 / F configuration /
F display / F sensor electronic / F sensor global / F sensor local /
F field current local / F current in-/output A / F current in-/output B /
F current output C / F software user interface /
F hardware settings / F hardware detection /
F RAM/ROM error IO1 / F RAM/ROM error IO2
Failure (application) F application error / F empty pipe / F flow rate too high /
F field frequency too high / F DC offset / F open circuit A /
F open circuit B / F open circuit C /
F over range A (current) / F over range B (current) /
F over range C (current) / F over range A (pulse) /
F over range B (pulse) / F over range D (pulse) /
F active settings / F factory settings /
F backup 1 settings / F backup 2 settings
Out of specification S out of specification / S pipe not full / S pipe empty /
S linearity / S flow profile / S electrode noise /
S gain error / S electrode symmetry / S field coil broken /
S field coil bridged / S field current deviation /
S field frequency too high / S electronic temperature /
S coil temperature / S overflow counter 1 / S overflow counter 2 /
S overflow counter 3 / S backplane invalid
check request C checks in progress / C test sensor
