OPERATION
6
119
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
C1.3.11 limit flow profile Not Not Not Not valid for CAP option (capacitive) and PF option (partly filled)!
Only with flow profile switched on, see Fct. C1.3.10.
Range: 0.000…10 (absolute values above this threshold generate an error of
category [S])
C1.3.12 act. flow profile Not Not Not Not valid for CAP option (capacitive) and PF option (partly filled)!
Only available when flow profile "on" activated in Fct. C1.3.10. Activation
takes place only after setting mode is exited!
C1.3.13 electrode noise Automatic test switched off / on.
Select: off /on
C1.3.14 limit electr. noise Only with electrode noise activated, see Fct. C1.3.13.
Range: 0.000…12 m/s (noise above this threshold generates an error of
category [S])
C1.3.15 act. electr. noise Only available when electrode noise "on" activated in Fct. C1.3.13. Activation
takes place only after setting mode is exited!
C1.3.16 settling of field Automatic test switched off / on.
Select: off /on
C1.3.17 diagnosis value Not Not Not Not valid for CAP option (capacitive) and PF option (partly filled)!
Select diagnosis value for testing the various analogue outputs.
Select:
off (no diagnosis) / electrode noise (activate Fct. C1.3.13) /
flow profile (activate Fct. C1.3.10) / linearity (activate Fct. C1.3.6) /
terminal 2 DC (electrode DC voltage) / terminal 3 DC (electrode DC voltage)
C1.3.17 diagnosis value Only Only Only Only valid for CAP option (capacitive)!
Select diagnosis value for testing the various analogue outputs.
Select: off (no diagnosis) / electrode noise (activate Fct. C1.3.13)
C1.3.17 diagnosis value Only Only Only Only valid for PF option (partly filled)!
Select diagnosis value for testing the various analogue outputs.
Select:
off (no diagnosis) / electrode noise (activate Fct. C1.3.13) /
terminal 2 DC (electrode DC voltage) / terminal 3 DC (electrode DC voltage)
C1.4 information
C1.4 information Grouping of all functions related to information with respect to measuring
sensor and sensor electronics.
C1.4.1 liner Shows material of the liner.
C1.4.2 electr. material Shows material of the electrodes.
C1.4.3 calibration date Not available at this time.
C1.4.4 serial no. sensor Shows serial no. of the measuring sensor.
C1.4.5 V no. sensor Shows the order number of the measuring sensor.
C1.4.6 sensor electr. info Sows serial number of circuit board, software version number and
calibration date of circuit board
C1.4.7 option PF info Only Only Only Only valid for PF option (partly filled)!
Shows serial number of circuit board, software version number and
calibration date of circuit board for partly filled pipes
