8
TECHNICAL DATA
156
IFC 300
www.krohne.com 08/2010 - 4000069803 - MA IFC 300 R04 en
8.3 Dimensions and weights
8.3.1 Housing
Dimensions and weights in mm and kg
Dimensions and weights in inch and lb
1 Compact version (C)
2 Field housing (F) - remote version
3 Wall-mounted housing (W) - remote version
4 19" rack-mounted housing 28 TE (R) - remote version
5 19" rack-mounted housing 21 TE (R) - remote version
Version Dimensions [mm] Weight [kg]
a b c d e g h
C 202 120 155 260 137 - - 4.2
F 202 120 155 - - 295.8 277 5.7
W 198 138 299 - - - - 2.4
R 142 (28 TE) 129 (3 HE) 195 - - - - 1.2
107 (21 TE) 129 (3 HE) 190 - - - - 0.98
Version Dimensions [inch] Weight [lb]
a b c d e g h
C 7.75 4.75 6.10 10.20 5.40 - - 9.30
F 7.75 4.75 6.10 - - 11.60 10.90 12.60
W 7.80 5.40 11.80 - - - - 5.30
R 5.59 (28 TE) 5.08 (3 HE) 7.68 - - - - 2.65
4.21 (21 TE) 5.08 (3 HE) 7.48 - - - - 2.16
