6
OPERATION
62
OPTIWAVE 5200 C/F
www.krohne.com 07/2013 - 4001904902 - HB OPTIWAVE 5200 R02 en
Measurement type definitions
6.3 Configuration mode
6.3.1 General notes
Change the settings of your device in Configuration Configuration Configuration Configuration mode. Data about the menus is given on page
68. You can:
• Use the 1.0.0 INFORMATION 1.0.0 INFORMATION 1.0.0 INFORMATION 1.0.0 INFORMATION menu to read settings, device software versions and error
records. For more data about the Information menu, refer to Table 1: Info.
• Use the 2.0.0 SUPERVISOR 2.0.0 SUPERVISOR 2.0.0 SUPERVISOR 2.0.0 SUPERVISOR menu to commission the device, to run diagnostic tests, set up a
conversion table for volume, mass or flow rate measurement, change critical parameters for
difficult process conditions, reset the device and change basic parameters (tank height etc.),
output settings, HART Address etc. For more data about the Supervisor menu, refer to Table
2: Supervisor.
Measurement name Description Available units
LEVEL This is a display and an output function option. It
is the height from the bottom of the tank to the
surface of the liquid (Tank height - Distance).
m, cm, mm, in (inches), ft
(feet)
DISTANCE This is a display and an output function option. It
is the distance from the face of the flange (or
thread stop) to the surface of the liquid.
m, cm, mm, in (inches), ft
(feet)
CONVERSION This is a display and an output function option. It
gives the volume or mass of the tank contents.
This data is available if you prepare a volume or
mass table in configuration mode. For data on
how to prepare the conversion table, refer to
How to configure the device to measure volume
or mass on page 81. If the device is used with
PACTware™ software, it can also show flow rate
in a channel. 6 flow profiles are available in the
menu: Parshall (ISO 9826), Venturi Rectangular
(ISO 4359), Venturi Trapezoidal (ISO 4359),
Venturi U (ISO 4359), V-Notch (ISO 1438) or
Rectangular Notch (ISO 1438).
m3, L, gal (US gallons), ImpG
(Imperial gallons), ft3, bbl (oil
barrel), kg, t, Ston, Lton, m,
cm, mm, in, ft, m3/h, ft3/h
ULLAGE CONV. This is a display and an output function option. It
gives the empty volume or remaining mass that
can be put in the tank. This data is available if
you prepare a volume or mass table in
configuration mode. For data on how to prepare
the conversion table, refer to How to configure
the device to measure volume or mass on page
81.
m3, L, gal (US gallons), ImpG
(Imperial gallons), ft3, bbl (oil
barrel), kg, t, Ston, Lton, m,
cm, mm, in, ft, m3/h, ft3/h
REFLECTION This is a display and an output function option. It
is the percentage of the emitted radar signal
which makes a reflection on the surface of the
liquid and is received by the device.
%
OUTPUT I (mA) The current output of the device. mA
OUTPUT I (%) The percentage of the current output. 0% = 4 mA.
100% = 20 mA.
%
INFORMATION!
It is not possible to enter the 3.0.0 SERVICE and 4.0.0 MASTER menus. These menus are for
factory calibration and approved personnel only.
