APPENDIX

10

147

OPTIWAVE 5200 C/F

www.krohne.com

07/2013 - 4001904902 - HB OPTIWAVE 5200 R02 en

Figure 10-3: Measurement definitions: distance

1 Distance
2 Dead zone
3 Flange facing
4 Gas (Air)
5 Tank height
6 Ullage volume or mass

Figure 10-4: Measurement definitions: level

1 Level
2 Volume or mass
