TECHNICAL DATA
104
OPTIWAVE 5200 C/F
www.krohne.com 07/2013 - 4001904902 - HB OPTIWAVE 5200 R02 en
Process connections
Thread PP Wave Horn antenna: G 1½; 1½ NPT
Flange version Flange version Flange version Flange version
EN PTFE Wave Horn antenna: DN50…150 in PN16, PN40
Metallic Horn and Wave Guide antennas: DN80…200 in PN16, PN40; others on
request
ASME PTFE Wave Horn antenna: 2¨…6¨ in 150 lb / 300 lb
Metallic Horn and Wave Guide antennas: 3¨…8¨ in 150 lb / 300 lb; others on request
JIS PTFE Wave Horn antenna: 50...150A in 10K
Metallic Horn and Wave Guide antennas: 80…200A in 10K; others on request
Other Others on request
Electrical connections
Power supply Terminals output - Non-Ex / Ex i: Terminals output - Non-Ex / Ex i: Terminals output - Non-Ex / Ex i: Terminals output - Non-Ex / Ex i:
12…30 VDC; min./max. value for an output of 22 mA at the terminal
Terminals output - Ex d: Terminals output - Ex d: Terminals output - Ex d: Terminals output - Ex d:
16…36 VDC; min./max. value for an output of 22 mA at the terminal
Maximum current 22 mA
Current output load Non-Ex / Ex i: Non-Ex / Ex i: Non-Ex / Ex i: Non-Ex / Ex i: R
L
[Ω] ≤ ((U
ext
-12 V)/22 mA). For more data, refer to Minimum power
supply voltage on page 108.
Ex d: Ex d: Ex d: Ex d: R
L
[Ω] ≤ ((U
ext
-16 V)/22 mA). For more data, refer to Minimum power supply
voltage on page 108.
Cable entry Standard: M20×1.5; Option: ½ NPT
Cable gland Standard: none
Options: M20×1.5 (cable diameter: 6...10 mm / 0.2...0.39¨); others are available on
request
Cable entry capacity (terminal) 0.5…2.5 mm²
Input and output
Current output / HART Current output / HART Current output / HART Current output / HART®
Output signal
4…20 mA HART ® or 3.8…20.5 mA acc. to NAMUR NE 43 3
Resolution ± 3 µA
Temperature drift Typically 50 ppm/K
Digital temperature drift Max. ±15 mm / 0.6¨ for the full temperature range
Error signal High: 22 mA; Low: 3.6 mA acc. to NAMUR NE 43 4
PROFIBUS PA PROFIBUS PA PROFIBUS PA PROFIBUS PA
Type PROFIBUS MDP interface that agrees with IEC 61158-2 with 31.25 kbit/s; voltage
mode (MDP = Manchester Coded Bus Powered)
Function blocks 1 × Physical Block, 1 × Level Transducer Block, 4 × Analog Input Function Blocks
Device power supply 9...32 VDC - bus powered; no additional power supply required
Polarity sensitivity No
Basic current 15 mA
