DEVICE DESCRIPTION
2
17
OPTIWAVE 5200 C/F
www.krohne.com 07/2013 - 4001904902 - HB OPTIWAVE 5200 R02 en
2.3 Visual Check
If the device is supplied with an FKM/FPM gasket, there is no symbol on the side of the process
connection.
INFORMATION!
Inspect the cartons carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
Figure 2-6: Visual check
1 Device nameplate (for more data, refer to Nameplate (examples) on page 18)
2 Process connection data (size and pressure rating, material reference and heat number)
3 Gasket material data - refer to the illustration that follows
Figure 2-7: Symbols for the supplied gasket material (on the side of the process connection)
1 EPDM
2 Kalrez
® 6375
3 PFA
