GDS-3000 Series User Manual
92
Maximum and
Minimum 1. To set a maximum and minimum
boundary, press Minimum Position
from the bottom menu and use the
Variable knob to select the absolute
minimum position.
Position Voltage division range
2. Press Minimum Position again to
toggle the menu to Maximum
Position. Choose the maximum
position.
Position Voltage division range
Note If a maximum and minimum
boundary is set, the tolerance will
be disabled.
Save Boundary
Limits 1. Select a Maximum Position or a
Tolerance from the lower menu.
2. To save the Go-NoGo test
parameters, press Save Operation.
The Maximum position will be
saved to R1. The tolerance
waveforms will be saved to R1 and
R2.
3. If a Maximum Position was saved,
repeat the save procedure for
Minimum Position. The Minimum
position waveform will be saved to
R2.
