SAVE/RECALL
155
6. Press Save Now from the side menu
to save the display as an image file.
Note
The file will not be saved if the
power is turned Off or the USB
drive is taken out before the
message ends.
USB File Utility To edit the USB flash drive contents
(create/ delete/ rename files and
folders) or to edit the default file path,
press File Utilities from the side menu.
See page 166 for details.
Save Image - Print/Save Key
Background The Print/Save key can be assigned to Print or to
Save. When assigned to Save, pressing the
Print/Save key will save a screen image to USB.
Panel Operation 1. Connect a USB drive to the
front or rear panel USB port.
Note: Only one host
connection, front or rear, is
allowed at a time.
Front Rear
Host
2. Press the Utility key.
Utility
3. Press Printout from the bottom
menu.
