APPENDIX

201

Display

TFT LCD Type 8" TFT LCD SVGA color display

Display Mode YT, XY

Display
Resolution

800 horizontal × 600 vertical pixels (SVGA)

Interpolation Sin(x)/x & Equivalent Time Sampling

Waveform
Display

Dots, vectors, variable persistence, infinite
persistence

Display
Graticule

8 x 10 divisions

Waveform
Update Rate

3500 waveforms per second maximum

Interface

RS232C

DB-9 male connector

USB Port

2 sets USB 2.0 High-speed host port
1 set USB High-speed 2.0 device port

Ethernet Port
(LAN)

RJ-45 connector, 10/100Mbps

SVGA Video
Port

DB-15 female connector, monitor output for
display on SVGA monitors

GPIB

GPIB to USB adapter (Option)

Go-NoGo
BNC

5V Max, 10mA CMOS open collector output

Internal flash
disk

64MB

Kensington
Style Lock

Rear-panel security slot connects to standard
Kensington-style lock.

Line output

3.5mm stereo jack for Go/NoGo audio alarm

Power Source Line Voltage

Range

AC 100V ~ 240V , 48Hz ~ 63Hz , Auto selection

Power
Consumption

96VA

Miscellaneous Multi-

language
menu

Available

On-line help

Available

Time clock

Time and Date ,Provide the Date/Time for saved
data

Dimensions

400W X 200H X 130D, Approx. 4kg
