CONFIGURATION
105
Real Time vs Equivalent Time Sampling Mode
Background The sampling mode on the GDS-3000 can be
switched between two sampling modes: Real-time
and Equivalent-time. The number of active
channels in operation will determine the sampling
rate of the DSO. The sampling rate and mode
depends on the number of active channels and
whether the oscilloscope model has 2 or 4
channels.
Parameter Real-time
sampling One sample of data is used to
reconstruct a single waveform.
Real-time sampling is used when
the time base is relatively slow or if
single shot events need to be
captured.
Equivalent-
time sampling Sampled data is accumulated a
number of times to reconstruct a
single waveform. This increases the
sampling rate, but can only be used
for repetitive signals. This mode is
usually used when the time base is
too fast for real-time sampling.
