MEASUREMENT

77

5. Use the Variable knob to move the

movable cursor(s) left or right.

VARIABLE

Left

Right

Example

Horizontal

cursors

FFT Math

FFT Math has different content.
For FFT math details, see page
85.

Cursor

Frequency, dB/V

Cursor

Frequency, dB/V

Delta (difference between cursors)

Example

Horizontal

cursors
