QUICK REFERENCE
43
Measure Key
Display automatic measurements either individually or as
voltage/current, time or delay measurement groups.
Measure
Remove
Measurement
Gating Display All
Off
(Full Record)
Add
Measurement
CH1
CH2
CH3
CH4
Off
Window 1
Window 2
Window 3
Window 4
Remove All
Pk-Pk
Max
Min
Amplitude
High
Low
Average
RMS
ROVShoot
FOVShoot
RPREShoot
FPREShoot
V/I
Frequency
Period
RiseTime
FallTime
+Width
-Width
Dutycycle
Time
FRR
FRF
FFR
FFF
LRR
LRF
LFR
LFF
Phase
Delay
Screen
Between
Cursors
CH1~CH4
Source 1
CH1~CH4
Source 2
