GETTING STARTED
13
 Three standard input impedances
(50Ω/75Ω/1MΩ)
 Optional power measurement functions are
available for fast analysis of power quality tests
 Optional analysis software for I 2 C, SPI and
UART serial signal triggering and decoding
 2 and 4 channel models available up to 500 MHz
 Large 8” color TFT LCD, supporting a large 8 x
10 graticule
 On-screen Help
 64 MB internal flash memory.
 FreeWave remote control software (free
download)
Interface  USB host port: front and rear panel, for storage
devices
 USB slave port(Optional GPIB to USB), RS-232C
port: for remote control
 Calibration output
 Go-No Go output
 Trigger output
 Ethernet port
Accessories
Standard
Accessories Part number Description
82DS-33040MA1 User manual
N/A region dependent Power cord
Options Option Number Description
DS3-PWR Power analysis software
DS3-SBD Series Bus analysis
software
