MEASUREMENT

67

Select Active
Channel

To select the active channel, press the
corresponding split window key:

4 Window split screen:

Window

1

Window

2

Window

3

Window

4

2 window split screen:

Window

1

Window

1

Window

2

Window

2

Reference
Waveforms

Reference waveforms can also be used in this
mode. Each reference waveform will be recalled to
the corresponding split window number. I.e., Ref1
will be recalled to the first split window, Ref2 to
the second window and so on.

Use Active
Channel Settings

To return to full screen mode using
the settings of the active channel,
press the

button.

Exit Split Window
mode

To exit split window mode, press the
Split Window key again.

Split

Window
