SAVE/RECALL
161
Acquire Mode: Sample XY: OFF
Sample mode: Sinc Sample rate: 250MSPS
(200MSPS GDS350X)
Display Mode: Vector Persistence: Auto
Waveform intensity: 50% Graticule intensity: 50%
Waveform visuals: Gray Graticule: full
Channel Scale: 100mV/Div CH1: On
Coupling: DC Impedance: 1MΩ
Invert: Off Bandwidth: full
Expand: By ground Position: 0.00V
Probe: voltage Probe attenuation: 1x
Deskew: 0s
Cursor Horizontal cursor: Off Vertical Cursor: Off
Measure Source1: CH1 Source2: CH2
Gating: Off Display: Off
Horizontal Scale: 10us/Div
Math Source1: CH1 Operator: +
Source2: CH2 Position: 0.00 Div
Unit/Div: 200mV Math Off
Test App: Go-NoGo
Trigger Type: Edge Source: CH1
Coupling: DC Alternate: Off
Rejection: Off Noise Rejection: Off
Slope: positive Level: 0.00V
Mode: Auto Holdoff: 10.0ns
