GETTING STARTED
33
Selecting a Menu
Item or Parameter When the user manual says to “select” a value
from one of the side menu parameters, first press
the corresponding menu key and use the variable
knob to either scroll through a parameter list or to
increase or decrease a variable.
1
2
3
Example 1. Press a bottom menu key to access
the side menu.
2. Press a side menu key to either set
a parameter or to access a sub
menu.
3. If accessing a sub menu or setting
a variable parameter, use the
variable knob to scroll through
menu items or variables. Use the
select key to confirm and exit.
VARIABLE
Up Down
Select
4. Press the same bottom menu key
again to reduce the side menu.
