APPENDIX
197
A
PPENDIX
GDS-3000 Specifications
The specifications apply when the GDS-3000 is powered on for at
least 30 minutes under +20°C~+30°C.
Model-specific
GDS-3152 Channels 2 + Ext
Bandwidth DC ~ 150MHz (–3dB)
Rise time 2.3ns
GDS-3154 Channels 4 + Ext
Bandwidth DC ~ 150MHz (–3dB)
Rise time 2.3ns
GDS-3252 Channels 2 + Ext
Bandwidth DC ~ 250MHz (–3dB)
Rise time 1.4ns
GDS-3254 Channels 4 + Ext
Bandwidth DC ~ 250MHz (–3dB)
Rise time 1.4ns
GDS-3352 Channels 2 + Ext
Bandwidth DC ~ 350MHz (–3dB)
Rise time 1ns
GDS-3354 Channels 4 + Ext
Bandwidth DC ~ 350MHz (–3dB)
Rise time 1ns
GDS-3502 Channels 2 + Ext
Bandwidth DC ~ 500MHz (–3dB)
Rise time 700ps
GDS-3504 Channels 4 + Ext
Bandwidth DC ~ 500MHz (–3dB)
Rise time 700ps
The bandwidth of the 75Ω input impedance is limited to 150MHz only.
