GDS-3000 Series User Manual
200
Acquisition
Mode Normal, Average, Peak Detect, High Resolution,
Single Sequence
Peak (Glitch)
Detection 2nS (MAX)
Normal: Acquire sampled values.
Average: From 2 to 256 waveforms included in
average.
Peak Detect: Captures glitches as narrow as 2 ns at
all sweep speeds
Hi Res: Real-time boxcar averaging reduces
random noise and increases vertical resolution
Cursors and
Measurement Cursors Amplitude, Time, Gating available
Automatic
Measurement 28 sets: Vpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax,
Vmin, Rise Preshoot/Overshoot, Fall
Preshoot/Overshoot, Freq, Period, Rise Time, Fall
Time, Positive Width, Negative Width, Duty Cycle,
and nine different delay measurements (FRR, FRF,
FFR, FFF, LRR, LRF, LFR, LFF, Phase)
Cursors
measurement Voltage difference between cursors ( ∆V) Time
difference between cursors ( ∆T)
Auto counter 6 digits, range from 2Hz minimum to the rated
bandwidth
Power
Measurements
(Option) Power Quality
Measurements V RMS, I RMS, True Power, Apparent Power,
Reactive Power, Frequency, Power Factor, Phase
Angle, V Crest Factor, I Crest Factor, (+)V Peak,
(-)V Peak, (+)I Peak, (-)I Peak, DC Voltage, DC
Current, Impedance, Resistance, Reactance
Harmonics Frequency (Hz), Magnitude (%), Mag. RMS (A),
Phase (˚), Limit (A), Limit (%), Pass | Fail, Max all ,
Windows (A), 200% Limit, POHC Limit, THD-F,
THD-R, RMS, Overall, POHC, POHL, Input Power,
Power Factor, Fundamental Current, Harmonic 3,
Harmonic 5
Ripple
Measurements Ripple, Noise
In-rush current First peak, Second peak
Control Panel
Function Autoset Single-button, automatic setup of all channels for
vertical, horizontal and trigger systems, with undo
autoset
Auto-Range allow you to quickly move from test point to test
point without having to reset the oscilloscope for
each test point
Save Setup 20 sets
Save
Waveform 24 sets
