GDS-3000 Series User Manual
30
First Time Use
Background
This section describes how to connect a signal,
adjust the scale, and compensate the probe. Before
operating the GDS-3000 in a new environment,
run these steps to make sure the instrument
performs at its full potential.
1. Power On
Follow the procedures on the previous page.
2. Set the Date
and Time
Set the date and time.
3. Reset System
Reset the system by recalling the
factory settings. Press the Default
Setup key on the front panel. For
details, see page 160.
Default
Setup
4. Install Optional
Software
The optional software packages
(Power Analysis, Serial Bus Decode)
can be activated.
5. Connect Probe
Connect the probe to the CH1 input terminal and
probe compensation signal output (2Vp-p, 1kHz
square wave).
Set the probe attenuation to x10 if the probe has
adjustable attenuation.
VOLTS/DIV
VOLTS/DIV
VOLTS/DIV
VOLTS/DIV
POSITION
POSITION
POSITION
TIME/DIV
POSITION
HORIZONTAL
VARIABLE
W
AC
BW
50
W
75
VERTICAL
LEVEL
POSITION
TRIGGER
W
AC
BW
50
W
75
W
AC
BW
50
W
75
W
AC
BW
50
W
75
CH4
CH3
CH2
CH1
EXT TRIG
POWER
2V
Window
Split
Select
Zoom
CH1
CH2
CH3
CH4
R
B1
Measure
Cursor
Display
Help
Test
Save/Recall
Utility
Menu
50 %
Force - Trig
Autoset
Single
Run/Stop
Setup
Auto-Range
Default
Acquire
M
B2
MATH
REF
BUS
Off
Menu
Save
x1
x10
X
1
0
X
1
