CONFIGURATION
141
6. Press Slope from the bottom menu
to toggle the slope.
Range Rising edge, falling edge, either
7. Press When from the lower menu.
8. Then use the side menu to select
the logic conditions and true or
false status.
Condition > , < , = , ≠
Width 4ns ~ 10s
9. Press Threshold from the lower
bezel to edit the threshold for each
input source.
10. Use the side menu to set the
threshold for the current input.
Range High: -XXV~XV
Low: -XXV~XXV
Set to TTL 1.4V
Set to ECT -1.3V
