Displaying BGP4+ information
9
This display shows the following information.
Displaying the best and unreachable routes received from a BGP4+ neighbor
You can display a summary or detailed information about the following types of BGP4+ routes
received from a specified neighbor:
•
Best routes – The “best” routes to their destinations, which are installed in the Virtual ADX
device’s IPv6 route table.
•
Unreachable – The routes whose destinations are unreachable using any of the BGP4+ paths
in the IPv6 route table.
For example, to display a summary of the best routes to a destination received from neighbor
2001:db8:2000:4::106, enter the following command.
TABLE 18
Detailed RIB route information for a BGP4+ neighbor
This field...
Displays...
Number of RIB_out routes for a
specified neighbor (appears
only in display for all routes)
For information about this field, refer to
Status codes
For information about this field, refer to
Prefix
For information about this field, refer to
Status
For information about this field, refer to
Age
The age of the RIB route, in seconds.
Next Hop
For information about this field, refer to
Learned from Peer
The IPv6 address of the neighbor from which this route is learned. “Local
Router” indicates that the Virtual ADX device itself learned the route.
LOCAL_PREF
For information about this field, refer to
MED
The value of the RIB route’s MED attribute. If the route does not have a metric,
this field is blank.
Origin
The source of the route information. The origin can be one of the following:
•
EGP – The routes with this set of attributes came to BGP4+ through EGP.
•
IGP – The routes with this set of attributes came to BGP4+ through IGP.
•
INCOMPLETE – The routes came from an origin other than one of the
above. For example, they may have been redistributed from OSPFv3.
When BGP4+ compares multiple routes to a destination to select the best
route, IGP is preferred over EGP and both are preferred over INCOMPLETE.
Weight
For information about this field, refer to
AS-PATH
For information about this field, refer to
Virtual ADX# show ipv6 bgp neighbor 2001:db8:2000:4::106 routes best
There are 2 accepted routes from neighbor 2001:db8:2000:4::106
Searching for matching routes, use ^C to quit...
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
E:EBGP H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED F:FILTERED
Prefix Next Hop Metric LocPrf Weight Status
1 2001:db8:2002::/16 2001:db8:2000:4::106 1 100 0 BE
AS_PATH: 65001
2 2001:db8:2002:1234::/32 2001:db8:2000:4::106 1 100 0 B
AS_PATH: 65001
